Drive-In Environmental Chamber
LIB · Walk-in & Drive-in Chambers
LIB drive-In environmental chambers are available in many sizes and configurations. Drive In chambers is designed for testing of any type vehicle such as automobiles with the capability to simulate weather environments from extreme heat and humidity to cold temperatures.
Datasheets
Features
- The drive-In environmental chamber enables whole vehicle testing. The chamber can simulate a variety of environmental conditions such as temperature, humidity, corrosion, altitude, sand and dust, rain, noxious gases and so on.
- From obtaining customer needs, to discussing solutions, production, transportation, installation and commissioning, LIB can realize one-stop solutions.
- LIB team responds quickly, has high work efficiency and can delivery the chamber as soon as possible.
Specification
| Internal dimension (mm) | 2500*2500*2500 D*W*H |
|---|---|
| Overall dimension (mm) | 4000*2550*2850 D*W*H |
| Temperature range | -60℃ ~ +150℃ |
| Humidity range | 20% ~ 95% RH |
| Temperature fluctuations | ± 2.0℃ |
| Humidity fluctuations | ± 5.0% RH |
| Heating rate | 3 ℃ / min |
| Cooling rate | 1 ℃ / min |
| Controller | Programmable color LCD touch screen controller; Ethernet port |
| Cooling system | Mechanical compression refrigeration system |
| Safety device | Humidifier dry-combustion protection; over-temperature protection; over-current protection; Refrigerant high-pressure protection; Water shortage protection; Earth leakage protection |
| Exterior material | Steel Plate with protective coating |
| Interior material | SUS304stainlesssteel |
