- ISO 11345: 2006
- ASTM D7725
- ASTM D7723
DisperTester 3000 Plus Dispersion
MonTech · Dispersion
The MonTech DisperTester 3000 Plus is the newest model of carbon black dispersion tester - computer aided, advanced digital reflected light microscopy brought to the next level. The DisperTester 3000 Plus is the most advanced instrument for reliable filler dispersion analysis based on the superior compliance, reproducibility and repeatability well known from the DisperTester 3000 series.
เอกสารดาวน์โหลด
- MonTech General Cataloguemontech-product-catalogue-2023.pdfดาวน์โหลด PDF
- MonTech Specimen and Die cuttingmontech-specimen-and-die-cutting-2021.pdfดาวน์โหลด PDF
- DisperTester 3000 Plus datasheeten-dispersion-low.pdfดาวน์โหลด PDF
ข้อมูลจำเพาะ
| International standards | ISO 11345 : 2006, ASTM D 7723 |
|---|---|
| Electrical Requirements | 80 - 250 VAC, 47 – 63 Hz, 1 Amps |
| Data Interface | USB 3.0 |
| Dimensions (H x W x D) | 180 mm x 220 mm x 375 mm |
| Weight | approx. 24 kg net |
| Magnification | 100 times magnification |
| Aperture Size | 12 mm x 3.5 mm |
| Agglomerate range | 1 µm to 250 µm |
| Focus | Fully automatic or manual |
| Image resolution | 10 Megapixel with Carl Zeiss telecentric optics |
| Data format | PDF, JPEG, ASCII |
| Sample preparation | Manual sample cutter with 100 Spare blades included |
| Electrical | 90-250 V, 1 Amp, 47-63 Hz, Single phase |
